Metal detectable silicone sheets contain additives that are visible to metal detector scanning equipment, so they can be easily identified by X-ray machines, solving the problem of mechanical seal rubber particles polluting the production line
Gaskets made of these food safe silicone sheets can be used for a long time at -50~200 degrees Celsius. This detectable food silicone has strong resistance to chemical and environmental degradation and is suitable for use in various harsh environments. It is also resistant to ozone, oxidation, UV light, corona discharge, cosmic radiation, ionizing radiation and general weathering
Metal detectable food safe silicone sheets are FDA compliant and 21 CFR 177.2600 compliant, making them capable of repeated and prolonged contact with food, making metal detectable food safe silicone suitable for highly sensitive food, beverage and pharmaceutical sealing and protection applications. The raw materials used to manufacture this material are listed in FDA regulations
Technical Specification
| Type |
No. |
Color |
Specific |
Hardness |
Tensile Strength |
Elongation |
TEARING |
Temperature |
Thickness (mm) |
Width (m) |
| Gravity (g/cm3) |
(shore A) |
(Mpa) |
at Break (%) |
STRENGTH (KN/m) |
Range (°C) |
|
|
| DCS |
60T/22KN |
Transparent |
1.3±0.05 |
60±5 |
>8 |
>450 |
>22 |
-50~200 |
1-10 |
1~1.5 |
OTHER COLOURS, HARDNESS AND TECHNICAL SPECIFICATIONS CAN BE AVAILABLE UPON REQUEST
Available in thicknesses: 1mm to 25mm
1mm to 6mm - Rolls: 1000mm -1200mm-2000mm wide x 10-20 meters long
8mm & 10mm – Rolls: 1000mm-1200mm wide x 5-10 meters long
Over 10mm thickness-Plates : 2500mm x 1000-2000 mm
Information of a technical nature is based on laboratory tests which either Meridian conducts or sends to an independent laboratory for testing for determination of uses as requested in writing by customer. Meridian believes these to be reliable. However, Meridian has no control over the application of the material to, or part of, the final product and therefore, Meridian makes no express or implied warranty of result, fitness or merchantability. The customer should determine reliability for the end use or particular application.
